Description
| Feature | Specification |
|---|---|
| Format / Max sheet size | ~ 720 × 1,030 mm (≈ 28.3″ × 40.6″) |
| Minimum sheet size | ~ 360 × 520 mm (≈ 14.2″ × 20.5″) |
| Max printing area | ~ 710 × 1,020 mm (single-sided) / 700 × 1,020 mm (double-sided) |
| Colours / Units | Various: 2 to 8 colour units, with perfecting (i.e. double-sided in one pass) versions in some models. |
| Press Speed (Max) | ~ 15,000 sheets per hour in many GL-40P / Advance models. |
| Sheet / Substrate Thickness Range | Typically ~ 0.04 mm to ~0.8 mm for GL-40 Advance; some models have option for up to about 1.0 mm. |
| Plate Size | ~ 800 × 1,030 mm (≈ 31.5″ × 40.6″) in many GL-40 Advance models. |
| Blanket Size | ~ 920 × 1,040 mm (including aluminum bar) in many models. |
| Feeder Pile Height / Delivery Pile Height | ~1,110 mm in Advance models shown in sample GL-40 Advance runs. |
| Width / Footprint / Physical Size | Width & length vary depending number of colour units and optional accessories (e.g. coater, UV, blower cabinets). For a typical 4-colour GL-40 Advance: length ~9,971 mm; width ~4,095 mm (or ~5,675 mm with blower cabinet) |
| Controls & Automation Features | – Automatic / Fully Automatic Plate Changing (APC or Full-APC) – Print Quality Control (PQC / PDC-SX) for density, register etc. – Automatic wash-ups (blanket, ink roller etc.) – Presets for size, thickness, feeder/delivery adjustments. |
